Bradbury, F. (Fred) · Manchester : John Heywood Ltd. · leaf 276
Fig. 285. the loom, over the warp yarn, or at the front, above the head of theweaver. PRINCIPLES AND VARIETIES OF HARNESS MOUNTING. 271 … Fig. 286 272 JACQUARD MECHANISM AND HARNESS MOUNTING. Fig. 285 is a perspective sketch of this system. The view isfrom the left front of the loom, a shows the tug board and b thecomberboard ; three repeats of the harness c are shown tied up tothe first hook of each row from front to back. Each row…
Textile machinery
