Bradbury, F. (Fred) · Manchester : John Heywood Ltd. · leaf 90
nce in figure weaving andhave proved to be of inestimable benefit to tins branch of the textileindustry. DOUBLE LIFT JACQUARD MACHINES. 85 This type of machine is representative of thesimplest class of the double acting series of Jac-quards. The chief details of the system will beillustrated and… … Fig. 76. Fg- 7: one row of needles, uprights, tug cords and harness, together withthe lifting knives of a 400 machine as seen from the left side of aright hand loom. Altogether the machine contains 51 rows ofneedles and uprights, each of which is a duplicate of the one illus- 86 JACQUARD MECHANISM…
Textile machinery
Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
