o the driving motor or motors. The rela-tion between them may be a second set of rods coupling the jack-shaft cranks to a similar pair on the motor; or the jack-shaftmay be driven through spur or herring-bone gears cut on theperiphery of the disk engaging pinions of one or more motors.These rod… … Quill Drive with Geared Motors. connection than in the case of steam driving through pistons.The advantages are that the removal of driving wheels does notinvolve electric complications, and that all driving wheels in the Oct., 1921.] Characteristics of Locomotives. 473 group act together, so that…
