lifters, 44, from which it passes over a roller. After passingthe lifters, the tablets are moved downwards by rotary disks, 116,118, the pins sliding in guides, and are transferred to an endlesschain, 30, which returns the tablets to the front of the tank. Thetablets are raised by rotary disks,… … Fig. 93. transverse blades at their rear edges, so that the glass sheet i.severed as it passes under a roller, 51. The tank is provided withan extension chamber, 74, fitted with a cap stone, 65, which canbe adjusted vertically and angularly by screwed rods, 66, and afront stone, 68, vertically…
