Society of Glass Technology · [Sheffield] · leaf 461
er 8th,1919).—Relates to a glass bottle, etc., making machine of theautomatic continuously-rotating frame type. The parts are 60 JOURNAL OF THE SOCIETY OF GLASS TECHNOLOGY. operated by cams, mounted on a central column, 7, Fig. 31, in theusual way, except the plunger, 158, which is pneumatically… … Each parison mould, 60, is mounted on a carriage, 41, which ismoved by gearing along an inclined track, 45, extending over asmall arc of the main frame. This movement takes place at thefilling point and is timed so that when the mould reaches the fillingpoint the carriage, 41, commences to move…
