machines; the upper ends of these troughs beingone above the other. The charges of glass are alternately directedinto these chutes by means of a hinged section, the upper or hingedend of which is in register with the delivery trough from the gob-forming apparatus whilst the lower end moves up and… … Fig 163. 285. A Glass-discharging Mechanism. E. S. Hutton,Lapel, Indiana (U.S.A. Pat., No. 1391957, September 27th, 1921.Filed March 26th, 1920, No. 368867).—Into the wall at the workingend of a tank is built adischarge member, 15, sothat its upper surface isabove the level of theglass, 12, while…
