and moves iton the lower part, g, which contains the adjusting-screen, I. Thewheel spindle, 55, is pressed forward by a weighted lever, 57, aspring, 60, tending to retract it. The shaft, o, is divided withinthe bearing, z, and the parts are connected, for example, by a spigotand socket joint. A… … Fig. 184. Filed December 12th, 1919, No. 344381).—The invention consistsof a horse for supporting glass cylinders after they have beendrawn, and provides means for supporting the cylinder evenlyat all points and means for facilitating splitting. The devicecomprises a number of trolleys, 12, coupled…
