Knitting; a manual of practical instruction in the mechanical details of all types of knitting machinery, their operation, adjustment, and care (1909)
American School of Correspondence, Metcalf, M. A. [from old catalog] · Chicago, American school of correspondence · leaf 125
Fig. 41. Cam Ring. shaft bracket bearing is a hand wheel J, for turning the machine l)yhand when occasion requires. Attached to the shaft arm is a beltshipper with belt and handle. On the shaft, inside the housing, isa bevel pinion K, which, meshing into the needle cylinder gear L,rotates the… … Needle Cylinder. (Fig. 40).The cylinder needles are re-ciprocated vertically in slots inthe periphery of the needle cylin-ders, as shown in the illustra-tion. Needle cylinders are us-ually constructed from steelforgings of good quality, as therequirements are very severe;the needle walls or lands…
