thejaw or extension of one side at the end. The two jawscontain the pin holes through which are transferred to thepin the total load carried by the column. These jaws orextensions are formed so as to fit in between the parts ofintersecting members, usually the upper or lower chordsand eye-bars. It… … Fig. 4. these post jaws as they commonly occur. As the figuresshow, they are formed by cutting away the flanges of theangles or channels forming parts of the posts and rivetingon the pin or thickening plates required to strengthenthe detail. The jaws form short columns whose lengthsshould be taken…
