Knitting; a manual of practical instruction in the mechanical details of all types of knitting machinery, their operation, adjustment, and care (1909)

American School of Correspondence, Metcalf, M. A. [from old catalog] · Chicago, American school of correspondence · leaf 290

An illustration from Knitting; a manual of practical instruction in the mechanical details of all types of knitting machinery, their operation, adjustment, and care, 1909, leaf 290 — raised, and thelower cam 112 throws the picking-finger 105, into the position shownin Fig. 157. At the same time, the motion of the cam-ring is changedfrom a continuous rotary to a rotary reciprocating movement, duringwhich movement neither cam 90 nor cam 97 performs any function.As one side of the… … 115 108 Fig. 157. move, and with it the standard and cam-plate, one of the lower cams117 of the plate rides under the finger and elevates it, thus causing theupper surface of one of the lugs 109 of the picker to throw that needleup out of action. As the finger finally rides into the slot 118 of…

Knitting machines

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
