Labor-saving looms : a brief treatise on plain weaving and the recent improvements in that line, with special reference to the Northrop looms manufactured by Draper Company, Hopedale, Mass., U.S.A (1905)

Draper, George Otis, 1867-1923, Draper Company · [Hopedale, Mass. : Draper Company] · leaf 106

An illustration from Labor-saving looms : a brief treatise on plain weaving and the recent improvements in that line, with special reference to the Northrop looms manufactured by Draper Company, Hopedale, Mass., U.S.A, 1905, leaf 106 — thecut. It is operated by a cam on the lower loom -halt and sotimed that it will not take up unles- the shuttle is picked. Thisprevents the thin places which arc sometimes formed on commonand old Northrop looms if the weaver turns the loom over byhand while mending warp or before starting the… … SECTION OF B MODEL LOOM CUT-MOTION WITHFULL TEN-INCH ROLL OF CLOTH. This cut is interesting in comparison with our later motion,which lias mam additional advantages. The fliter or reed-holder shown is not now used. io4
