Labor-saving looms : a brief treatise on plain weaving and the recent improvements in that line, with special reference to the Northrup looms manufactured by Draper company, Hopedale, Mass., U. S. A. (1904)

Draper, George Otis, 1867-1923 · Milford, Mass. : Printed by Cook & sons · leaf 111

An illustration from Labor-saving looms : a brief treatise on plain weaving and the recent improvements in that line, with special reference to the Northrup looms manufactured by Draper company, Hopedale, Mass., U. S. A., 1904, leaf 111
SECTION OF B MODEL LOOM CUT-MOTION WITHFULL TEN-INCH ROLL OF CLOTH. This cut is interesting in comparison with our later motion,which has many additional advantages. The fliter or reed-holder shown is not now used. I04 … ORIGINAL HIGH ROLL CUT-MOTION FOR EMODEL LOOM. The cut illustrates our earliest pattern of High Roll cut-motion. It was quickly superseded bv the next type shown. I05

Looms

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
