The watchmakers' lathe, its use and abuse; a story of the lathe in its various forms, past and present, its construction and proper uses (1903)
Goodrich, Ward L. [from old catalog] · Chicago, Hazlitt & Walker · leaf 119
sizes, and is agreat convenience and saving of time for any one using therest. Fig. 98 shows a longitudinal section of the Webster-Whit-comb slide rest with three slides. This is also shown inelevation at Fig. 99. This has proven a very popular formof slide rest and has been imitated by a number of… … CI oo bQG c S3.2o 73 3 So o»4 3 E THE AMERICAN LATHE. II9 by a T bolt and eccentric in the same manner as the head ortail stock of a lathe is fastened. The slot for the tool postis placed parallel to and very close to the end of the upperslide, with the result that a very short tool may be used…
Clocks and watches · Lathes
