Moss, Sanford A. (Sanford Alexander), b. 1872 · New York, D. Van Nostrand company · leaf 15
Fig. 1. Reynolds Latch Mechanism. The steam valves are operated some-what differently. Each steam link oscil-lates a bell crank/ which is loose onthe steam valve stem. On this bellcrank is a latching gear of some kind 12 which is arranged to take hold of a steamarm directly attached to the steam… … SAFETY CAM Fig. 2. Latch Raising Valve. is thus made to follow it, and therebyopen the steam port. Plate I shows thetype of latch mechanism originated byEdwin Eeynolds, and now generally used,and Figs. 1, 2, and 3 show the mechan- 13 ism to a larger scale. Eeferring to theoutline sketch, Fig. 2, 0…
Corliss valve gears · Machine design
