Ludy, Llewellyn V., 1875- [from old catalog], American Technical Society · Chicago, American technical society · leaf 189
liss Drop Cut-Off Gear The valve is usually opened by means of links or rods moved by aneccentric and, at the proper point of cut-off, the rod is disengagedfrom the valve, which drops shut, hence the term drop cut-off gears.Reynolds=Corliss Gear. The most widely known drop cut-offgear is the… … ~~t-£ASHPQT BOD Fig. 7S. Details of Reynolds Hook plate, pivoted at the center of the cylinder. It transmits motion toeach of the four valves through adjustable links known as steam rods VALVE GEARS 87 or exhaust rods, according to whether they move the admission orexhaust valves. The valves which…
Indicators for steam-engines · Steam-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
