Modern locomotive engineering, with questions and answers .. (1913)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & co · leaf 554
Fig. 230), andthrough port /in the rotaryseat(Sec. 3, Fig.229), through apassage (/), andunder the sup-ply valve to thetop of the dia-phragm piston,then through aport (shown bydotted lines,and marked i,Sec. 2, Fig.230), whichleads off the topof the piston into the trainpipe by way of the mainsupply…
Locomotives
