Lessons in practical electricity; principles, experiments, and arithmetical problems, an elementary text-book (1903)
Swoope, Coates Walton. [from old catalog] · New York, D. Van Nostrand company · leaf 354
Fig. 303.—Bipolar Dynamo or Motor. DYNAMO ELECTRIC MACHINES. 335 … Fig. 304.—Dissected Bipolar Dynamo. F-Frame. LIST OF PARTS. A-Armature. C-Comumtator. C-Field coil complete. P-Part. B-Brush. VV-Screws. FRAME-F. Base, Field magnet, Pillow blk., lower part,Pillow blk., lower part comm. end,Pillow blk.,cap,Rocker arm,Binding post saddle,Journal box,Oil ringsOil…
Electricity · Magnetism
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
