Lessons in practical electricity; principles, experiments, and arithmetical problems, an elementary text-book (1902)
Swoope, Coates Walton. [from old catalog] · New York, D. Van Nostrand company · leaf 297
Fig. 240.—The Movable Current-Carrying Coil is Repelled bythe Stationary Bar Magnet. l)le Tinsel Wire Winds .\round the Magnet when a Current is Sent direction. Through it. ^i^g t-^-^ggl itself around the magnetthat the polarity at Nfield as before. lines of force of both are in the same When the… … Fig. 242.—Rotation of aCurrent-Carrying WireAround a Mag-netic Pole. 267. Rotation of a Current-Carrying Wire Around aMagnetic Pole.—Since the tendency of a magnet is to urge awire carrying a current to a position at right angles to it, con-tinuous rotation of the wire can be pro-duced if the wire…
Electricity · Magnetism
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
