A needle, free to move, takes up a position in the earthsmagnetic field with its magnetic lines parallel with, and inthe same direction as the earths lines of force. When amagnet is approached to it, it assumes a position which isthe resultant of the two forces now acting upon it. Xo effectis… … Fig. 47.—Needle Deflected Through Non-Magnetic Body. magnetising the iron plate by induction. The needle pro-duces a similar effect on the other side of the plate, and beingfree to move, deflects slightly, until its lines of force are pro-portionately accommodated between the earths magnetismand…
