iler and finally turns downward, so tliHt thefeed water is discharged between the tubes and the shell in the coolest part of the boiler.The feed water, being compelled to traverse the entire length of this long pipe, has timeto acquire a hii^h temperature betOTe<;oming in contact with any part… … Fig. 2. course of the pipe is fully shown. The back end of the pipe should be suspended fromthe head braces to keep it in position as shown. Fig. 3 shows the arrangement of pipes for a battery of two or more boilers. Inthis case a larger pipe, from two to two and one-half inches in diameter,…
