frame of the carriage. To the base of the frame is attached an adjustable strut, ordistance rod, by which its relative position, as regards the rearaxle, may be varied by a right-and-left threaded nut, or turn-buckle. By this device the slack of the chain may be taken up,and, to allow for the… … AUXILIARY THROTTLE i THROTTLE I EVER =0=0 LEVER FOR REVERSINGBY PASS LSVt.fi Fig. 451.—Plan Arrangement of the Locomobile1 Steam Carriage, showing position of the parts indicated in Fig. 245. in connection with Fig. 144. It is supplied by a small plungerpump operated from the crosshead of the…
