Fig. 1.—Front View of External Furnace as Applied to Upright Boilers. as applied to horizontal boilers. Many of these furnaces are in operation to-day, burn-ing the waste of saw-mills, pulp-mills, and tanneries, with good results. The presentillustrations show this furnace as adapted to vertical… … layy.J THE LOCOMOTIVE. 83 lltf urmngement of the furnace is substautially tlic .saiMo for boilers of tlie locomotivetype. Fig. 1 is a front view of the furnace, showing a section of it tlirough the middle•of tlie front tiring-hole. Fig. 2 is a side elevation of the whole, showing it in sectioni»s…
