Hartford Steam Boiler Inspection and Insurance Company · Hartford, Ct. : Hartford Steam Boiler Inspection and Insurance Co · leaf 109
Figs. 2 and 3.—Vertical and Horizontal Sections Trough Exploded Tank. lower than the sewer, and the water blown off from the boilers was transferredfrom the tank to the sewer by means of pumps. The vent pipe, for the escapeof steam, was 4 in. in diameter near the tank, but within a short distance…
Locomotives · Steam-boiler explosions
Internet Archive · Carnegie Library of Pittsburgh · Public Domain Mark 1.0. Free to use for anything.
