Hartford Steam Boiler Inspection and Insurance Company · Hartford, Ct. : Hartford Steam Boiler Inspection and Insurance Co · leaf 83
nds, that will have to be sustained by each single beam.Thus in Fig. 4, if A is given in inches, and IV in pounds, then the maximumbending moment that each single beam will have to sustain is WA/4. Bending Moment Due to Three Boilers.— To find the maximum bendingmoment when there are three boilers… … Fig. 5.—Three Boilers between Supports. the central boiler to the nearest point of support, add twice the horizontal distance,also expressed in inches, from the central line of one of the outside boilers to thenearest point of support. Multiply the sum by the weight of one of the boilers(together…
Locomotives · Steam-boiler explosions
Internet Archive · Carnegie Library of Pittsburgh · Public Domain Mark 1.0. Free to use for anything.
