31)1.375 X 55,ooo] + [5 X 1-375 X 1.156 X95,000] = [224,500] -f [755,ooo] = 979,500 lbs. Formula F can usually be neglected without computing its valuebecause its value, as a rule, is high. It is not advisable to do this,however, until one is thoroughly acquainted with riveted joint cal-culations.… … I|. Rive* Holes. Fig. 2. Another type of reinforced tube ligament which is quite frequentlymet is shown in Fig. 2. Here we have two rows of tubes enter-ing the drum running parallel to, and alongside of, the butt seam. Inthis way double use is made of the cover plates, first, as butt strapsfor the…
Locomotives · Steam-boiler explosions
