Kirkman, Marshall M. (Marshall Monroe), 1842-1921 · New York and Chicago, The World railway publishing company · leaf 183
arts subje 174 LOCOMOTIVE APPLIANCES. When the filling plug is unscrewed sufficiently toallow the steam to escape, the valve in the bottomcloses and the oil cup can be readily filled withoutclosing the main steam valve. When the filling plugis again screwed into position the valve in the bottomis… … Fig. i.Penberthy Ejector. It is a device, simple in construction, compact inform, convenient to handle, has no movable parts andcannot get out of order. Fig. 2 shows the position in which an ejector shouldbe placed for high elevations. For lifting only theejector can be placed at the boiler level.…
Locomotives
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
