Fig. 5. Detroit Triple Feed Locomotive Lubricator. Sectional view of feed—showing automatic safety valves above the glasses. hand cut, and place the glass in position. Thenscrew the sleeve V in place, and tighten up the glandnuts. To remove the glass, first unscrew the gland nutsand push the upper… … Fig. 6. Detroit Triple Feed Locomotive Lubricator. Showing manner of inserting and removing sight-feed glass. THE DETROIT TRIPLE-FEED LOCOMOTIVE LUBRI-CATOR WITH TIPPETT ATTACHMENT. The tippett attachment has been designed to insurethe regular delivery of the oil to the wearing parts byovercoming…
