hown in this spring, .108x6 gives us a deflectionof .648 inch with a load of 7,854 pounds. 190. Radius Bar.—Will you give me the propername for what I call the tongue of an engine truck to ?consolidated locomotive? Answer.—^This class of engine has what is called apony or Bissell truck, and the… … Deflection of Coil Spring. 138 LOCOMOTIVE BREAKDOWN QUESTIONS Our superintendent of motive power claims to bore themI-64-inch larger than the journal and let them go withoutfitting. Answer.—It is common practice to file out the crownof the brass about 3 inches wide and file or scrape to agood…
