ion is imagined to be taken through therim and hub on the line / z- and turned around to the posi-tion /;/;/, and the two arms are shown in projection as ifthey were directly back of the line ;// ;/. Draw the centerline / (/ and the sections of the rim as shown. Draw thearms from the dimensions…
