tubing arranged as clearlyshown in the illustrations; it is easy to exchange a defectivesuperheater for a new one, or to get at the end of a defectivetube. Two valves in the steam passages and directly over theends of the tubing provide for cutting out the superheater ifit fails on the road. The… … SCALE AND MUD. 189 separately from the boiler. Considering only the latter: thethrottle valve is in a steam box separate from the rest of thedome. The steam enters the end ofthe dry pipe noted outside the throttle-valve steam box, passes back to anddown through the superheater and upagain to the…
