Locomotive text for engineers and firemen; a complete treatise on the engine, electric head-light and standard code of train rules (1908)
National correspondence school of railroading, Chicago. [from old catalog] · [Chicago] · leaf 297
ion of this superheater isthe T-pipe, the regular conventional T-pipe being replacedby one of special design, shown in Plates 128, 129 and130. This T-pipe is subdivided into two compartmentsby a horizontal partition, and extends nearly across thesmoke-box, so that steam entering the T-pipe from… … SUPERHEATED STEAM. 287 Each header casting is also subdivided into two com-partments, in this case by a vertical partition, and five pipesor flues of one and one-sixteenth inch outside diameterare inserted through holes in the front wall of eachheader. These one and one-sixteenth inch tubes are…
Locomotives
