Locomotive catechism; an up-to-date, practical and complete work on the locomotive--treating on the design, construction, repair and running of all kinds of locomotives .. (1908)
Grimshaw, Robert, 1850- [from old catalog] · New York, The N. W. Henley publishing company · leaf 262
d be a mechanical equivalent of the former. THE STEPHENSON LINK. 0. Arc link-motions very common, in which, when the eccen-tric centers are between the axle and the link, the rods arecrossed? A. Xo; except with independent cut-off motions. 0. What special advantage zcould there be in a… … Fig. 156. Stephenson Link, Crossed Rods. 0. Are the eccentric rods of the Stephenson valve gear everso arranged as to be crossed instead of open or uncrossed,zchen both eccentrics are on the same side of the axle as thelink? A. Yes; in some engines they are arranged so as to be as
Locomotives
