Locomotive catechism; an up-to-date, practical and complete work on the locomotive--treating on the design, construction, repair and running of all kinds of locomotives .. (1908)
Grimshaw, Robert, 1850- [from old catalog] · New York, The N. W. Henley publishing company · leaf 59
ubbard fire-box? A. A predecessor of the YVootten, from which it differsonly in the absence of a combustion chamber. 0. What is the advantage of having the fire-box betweenthe axles? A. To get a deep box, as for soft coal. 0. JVhat is the disadvantage of having the fire-box abovethe axles? A. It… … Figs- 34, 35 and 36. Vanderbilt Fire-Box. THE FIRE-BOX. 57 [This Arrangement cf Heater andHtilcg3 •will answer for any classjof Tank. Possibly outlet to burnerpay have to be larger if it is neces!sary to make larger Burner fcrMastodon 01 Consolidation Engines
Locomotives
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
