Locomotive catechism; an up-to-date, practical and complete work on the locomotive--treating on the design, construction, repair and running of all kinds of locomotives .. (1908)
Grimshaw, Robert, 1850- [from old catalog] · New York, The N. W. Henley publishing company · leaf 709
nder frame. Q. How can a wheel be skidded to the next side track, ifthere is a piece broken out? A. By laying a tie in front of that pair of wheels. Q. Should the wheel centers be out of tram, how can youfind which pair is out? A. By calipering between the frame and the flat wheel facesat the… … Fig. 402. Broken Wheel Hub. A. By a dovetail or dumbbell piece, fitting in an openingmade by slotting out between two drill holes, The pieceshould be driven in hot and let draw the parts together. Therecess should be undercut (Fig. 402). ACCIDENTS TO AXLES. 695 ACCIDENTS TO THE AXLES. Q. What…
