Locomotive text for engineers and firemen; a complete treatise on the engine, electric head-light and standard code of train rules (1908)
National correspondence school of railroading, Chicago. [from old catalog] · [Chicago] · leaf 120
e trap for the purpose of removing wet sand or anyother obstruction which may lodge in the trap. Regulation of Sand Delivered. To regulate theamount of sand to be delivered to the rail it is necessaryto increase or decrease the space 3 between the end ofthe nozzle and the discharge pipe, by… … Plate 27 LEACH E DOUBLE SANDER no AIR SANDERS.. Care should be taken to adjust the nozzles on theopposite sides of the engine to correspond with eachother, in order that the volume of sand delivered to therails on each side of the engine will be equal. When more than one delivery pipe is connected…
