her; the surface which bears on the valve remains alwaysparallel to itself. It will be apparent that any desired pres-sure of contact can be made between the sliding-valve and thepressure-plate while the pressure of steam is kept from theback of the valve. The type selected will also serve to… … 200 MECHANICAL ENGINEERING OF POWER PLANTS. in Fig. 166, where the pressure-plate adjusts across the pathof the valve by similar inclined surfaces. The same engineis shown in Fig. 146. Or, again, the pressure-plate may bear-upon flat surfaces, from which it is held away by packing-
