Locomotive text for engineers and firemen; a complete treatise on the engine, electric head-light and standard code of train rules (1908)
National correspondence school of railroading, Chicago. [from old catalog] · [Chicago] · leaf 235
PLATE 103. BROKEN SPRING, HANGER OR EQUALIZER WITHOVERHUNG RIGGING—TEN-WHEEL ENGINE. If a front spring hanger, front spring or backhanger of front spring breaks on an engine withoverhung spring rigging, and the equalizers are be-tween the top and lower rails of the frame, the backdriver should be…
