f the sprocket, E being the point of contact for the driverand 7 a similar point for the follower when the rotation is asindicated. Each rivet consists practically of two pins called by the makersthe rocker pin and the seat pin. Each pin is fastened in itsparticular gang of links and the relative… … 200 MACHINE DESIGN tation of the engaging tooth profiles, gives a chain which can besafely run at high speeds without objectionable vibration orappreciable wear. The chains can be made of almost any width from h in. up to18 in., the width depending upon the pitch of the chain and thepower to be…
