Benjamin, Charles H[enry], 1856- [from old catalog] · New York, H. Holt and company · leaf 278
ximumat the edge as shown indiagram B, Fig. 109, whereby proportion we canreadily obtain the relativeresistance offered by themetal at the center as com-pared to that at the edge ofthe section. The loss atthe center is more thantaken up by the additionof a fraction of an inch at the edge or a very… … JZ T Fig. 109. 246 MACHINE DESIGN The size of the boss, if any be added, is largely optional and isput on for finish, 130. Screw Fastening for Standard.—In deciding upon thekind of fastening between the standard and the bed, it would bewell to first examine it regarding the turning moments about…
Machine design
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
