Benjamin, Charles H[enry], 1856- [from old catalog] · New York, H. Holt and company · leaf 282
if W^ were figured for double shear. To obtain the size of the pin to resist bending assume some TOGGLE-JOINT DETAILS 249 length of pin between the outer forces --, as 2 in. or 3 in., and solve by the formula TF7-8 = >SZ. See Art. 4. There mightbe a question raised here concerning the proper… … Fig. 114. fixed at the ends and loaded at the middle. If >S = 8000 andZ = 2, then 900X2-8 = 8000X71^^^^32; d = .65 say-11 in. The toggle action on the pin at the center requires that thesmaller force W should come at the center of the length of thepin as shown in A and B, Fig. 113. If the…
Machine design
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
