Mechanical drawing self-taught: comprising instructions in the selection and preparation of drawing instruments, elementary instruction in practical mechanical drawing together with examples in simple geometry and elementary mechanism, including screw threads, gear wheels, mechanical motions, engines and boilers (1883)

Rose, Joshua · Philadelphia, H.C. Baird & Co.; London, S. Low, Marston, Searle & Rivington · leaf 105

An illustration from Mechanical drawing self-taught: comprising instructions in the selection and preparation of drawing instruments, elementary instruction in practical mechanical drawing together with examples in simple geometry and elementary mechanism, including screw threads, gear wheels, mechanical motions, engines and boilers, 1883, leaf 105
I04 MECHA hUCAL DKA WING SELF- TA UGHT. when In place upon the machine pf which it formsa part. Thus in Fi^^ure 140 is a lever, and if its shaftstood horizontal when the piece is in place in the … Fig. 141. machine, the view given is an end one, but supposethat the shaft stood vertical, and the same view^ be-comes a plan or top view» 1 r. A ^ Fig. 142. THE ARRANGEMENT OF DIFFERENT VIEWS. 105 In Figure 142 Is a view of a lever which is a sideview if the lever stands horizontal, and lever B…

Mechanical drawing

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
