Benjamin, Charles H[enry], 1856- [from old catalog] · New York, H. Holt and company · leaf 360
Fig. 186. 183. Assignment.—Having given the path of a groove ABC,a follower block is to move from A to 5 to C to 5 to A. Designa mechanism without the use of cams, and without allowing anypart of the driving mechanism to extend within the angle ABC.Rack and pinion, or chain drives cannot be used…
Machine design
