Benjamin, Charles Henry, 1856- [from old catalog], Hoffman, James David, 1868- [from old catalog] joint author · New York, H. Holt and company · leaf 202
. 82 is illustrated a simple bearing for counters. Thesolid cast-iron box B with a spherical center is fitted directly in asocket in the hanger H and held in position by the cap C and a setscrew. There is not space here to show all the various formsof hangers and floor stands and reference is made… … 184 MACHINE DESIGN metal disposed to secure the greatest rigidity possible. Coredsections are to be preferred, Fig. 83 illustrates the proportions of a Sellers line-shaft hanger.This type is also made with the lower half removable so as tofacilitate taking down the shaft. Fig. 84 shows the outlines…
Machine design
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
