Benjamin, Charles Henry, 1856- [from old catalog], Hoffman, James David, 1868- [from old catalog] joint author · New York, H. Holt and company · leaf 369
Fig. 200. 334 MACHINE DESIGN 202. Assignment.—Required to design the mechanism for awriting cam as shown in Fig. 201. The sliding block X is movedby screw connection. All sizes to be selected by the student.Such a cam may be used for outlining any simple figure in designas well. … KINEMATIC PROBLEMSMechanism of the Rites Inertia Governor 335
Machine design
