Benjamin, Charles H[enry], 1856- [from old catalog] · New York, H. Holt and company · leaf 107
strength and deflection calculated by the usualformulas. In such a spring the bending and the stress aregreatest at some one point and the curvature is notuniform. To correct this fault the spring is made of a constantdepth but varying width. If the spring is fixed at one end and loaded at theother… … 82 MACHINE DESIGN. rhombus. The deflection of such a spring is one anda half times that of a rectangular spring. As such a springmight be of an in-convenient width,a compound or leaf-spring is made bycutting the trian-gular spring intostrips parallel to theaxis, and piling oneFis- 34- above another…
Machine design
