Benjamin, Charles H[enry], 1856- [from old catalog] · New York, H. Holt and company · leaf 115
Fig. 33 shows a gibbedslide for holding downthe back of a lathe car-riage with two adjust-ments. The gib g is taperedand adjusted by a screwand nuts. The saddleof a planing machine orthe table of a shaper usually has a rectangular gibbed Fig. 32.
Machine design
