Benjamin, Charles H[enry], 1856- [from old catalog] · New York, H. Holt and company · leaf 169
gt; | {L£l3 less rigid than theclosed hanger andis suitable onlyfor light shafting.The countershafthanger shown inFig. 70 is simple,strong and sym-metrical and is agreat improve-ment over thoseFig. 70. using pointed set screws for pivots.Hangers similar to this are used by the Brown &Sharpe… … shaft 100 H P 200 rev. per min ine shop 30 HP 120 rev. per min rn shop 50 HP 250 rev. per min 3 shop 20 HP 200 rev. per min 2. Determine the horse-power of at least two lines ofshafting whose speeds and diameters are known. 3. Design and sketch to scale a flange coupling for a threeinch line shaft…
Machine design
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
