a double - riveted butt joint in whichstrap is made wider than the outer and an extra row of rivets added, whose pitch is double that ofthe origi-nal seam ; this is sometimes called diamond riveting. See Fig.II. … Fig. II. This outer row of rivets is then exposed to singleshear and the original rows to double shear. Consider a strip of plate of a widths2 p. Thenthe resistance to tearing along the outer row of rivetsis (2p—d)tT As there are five rivets to compress in this stripthe bearing resistance is 5dtC…
