Machine design; a manual of practical instruction in designing machinery for specific purposes, including specifications for belts, screws, pins, gears, etc., and many working hints as to operation and care of machines (1918)
Wallace, Ernest L · Chicago, American technical society · leaf 57
Fig. 16. Bolt Fig. 16. A stud is a bolt in which the head is replaced by a thread;or it is a cylindrical bar threaded at both ends, usually having a smallplain portion in the middle, Fig. 17. The object of bolts and studsis to clamp machine parts together, and yet permit these same partsto be… … tension in the bolt. Studs and tap bolts pass through one of the con-nected parts and are screwed into the other, the stud remaining inposition when the parts are disconnected. As all materials are elastic within certain limits, the action ofa bolt in clamping two machine parts together, more…
Machine design
