Machine drawing; a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1914)
Griffin, Charles Lewis, 1867-, Adams, Charles Clyde, 1882- joint author · Chicago, American technical society · leaf 27
entions are shown in Fig. 17. Herea represents a single, right-hand, square thread; b, a single, right-hand, sharp V thread, and its modifications, the United StatesStandard or Sellers thread, and the Whitworth thread; c representsa left-hand, sharp thread; d is the most common convention for… … f^^^ f-^ Fig. 17. Conventional Representations of Screw Threads sents a standard pipe thread, the taper on the sides of the pipe beingneglected. There are other conventions for threads in use, but the aboveare the most important ones. These certainly can not be mistakenfor anything else, which is…
Machinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
